Synology Resurrection

Yesterday, I did something that apparently several decades of experience and reading endless horror stories can still not completely protect against: I typed rm -rf / with admin privileges on my primary data storage NAS. Fat fingered the enter key while typing out the full path to the thing I actually wanted to delete. Mental note for the future: put -rf at the end of the command, not the beginning…

I cancelled it in a split second, but the damage had been done. I could no longer log in via the web UI, SMB access was broken, and a lot of other things were clearly suspect.

I have offsite backups of all the actual data on there, so I wasn’t especially worried about losing anything irreplaceable, but I was filled with dread about spending the rest of my evening rebuilding the nas, it’s configuration, and having to go through a multi-day process to backup and restore terabytes of data. Since I could still access the data and that wasn’t affected, it would have made more sense to copy everything off it, versus restoring from my offsite. That would probably take days to download; either option would mean work and this thing being out of service for quite some time.

A year ago, I would absolutely have torn this thing down and done a fresh install. Today, this was a problem for Claude Code. And Claude was able to solve it in about an hour in a half. Below is Claude’s recollection of the incident, and the timeline, in their words.

Timeline

It started with a message that strikes fear into any sysadmin’s heart: “I accidentally deleted some critical files from my NAS.”

The patient was a Synology DS218j — a little two-bay NAS quietly humming away, holding years of data. The symptoms were grim: the DSM web interface was dead, SMB file sharing had collapsed, and most services weren’ working. A full factory reinstall would mean wiping everything and starting from scratch. We decided to try something harder.

SMB Rises From the Ashes

~17:11

The first problem to tackle was Samba. When smbd tried to start, it was panicking immediately with a cryptic reinit_after_fork() error. A bit of digging revealed the culprit: Linux’s Address Space Layout Randomisation (ASLR) was set to level 2 — full randomisation — and Samba 4.15.13 on ARM simply can’t cope with that. It needs level 1.

A one-liner fixed it:

1
echo 1 > /proc/sys/kernel/randomize_va_space

SMB came back to life. We wrote the fix into /etc/sysctl.conf so it would survive a reboot, then manually restarted smbd through its service scripts. File sharing: restored.

The Web UI: A Three-Headed Problem

~17:27

Getting the DSM web interface back was trickier. It turned out three separate things had gone wrong simultaneously.

Problem one: The web UI kept saying “system getting ready, try again later” (error 499). This turned out to be DSM checking a tiny file — /run/boot_seq.cfg — for a line reading STEP=4, meaning “boot is complete.” The file didn’t exist. We created it. The 499 went away.

Problem two: Without the file, synoscgi (DSM’s web backend) had nowhere to put its socket. We started it manually with the right environment variables:

1
SOCKET=/run/synoscgi.sock LD_PRELOAD=/usr/lib/openhook.so \
2
  /usr/syno/sbin/synoscgi --mode=scgi --task-per-worker=32

The login page appeared.

Problem three: Logging in still hung with a spinner forever. Tracing through the system, we found that /var/run/synocgid/ — the directory holding synocgid’s 15 authentication sockets — had been deleted along with everything else. synocgid was running, but deaf. We killed it and restarted it clean, and it recreated all 15 sockets. The spinner vanished.

We wrapped all three fixes into a systemd service (syno-boot-workaround.service) so the NAS could survive a reboot in its broken state while we worked on the real problem.

The Real Problem: Missing Binaries

~17:30

The DSM web UI was now reachable, but login still hung. Digging deeper, we found lists in /tmp/bin_broken.txt and /tmp/sbin_actual.txt — DSM’s own record of what was missing. The damage was extensive: 289 binaries missing from /usr/syno/bin/ and 164 from /usr/syno/sbin/. Core tools, authentication helpers, disk utilities — all gone.

The obvious fix was a firmware reinstall via synoupgrade --patch. We had a second NAS (DS423+, same DSM version) available to borrow files from — except it was x86_64 and the DS218j was armv7l. Every binary on one was useless on the other.

So we turned to the firmware itself.

The Upgrade Gauntlet

18:02–18:13

We downloaded the full 305MB firmware package — DSM_DS218j_86009.pat — directly to the NAS. Then synoupgrade --patch spat it back:

1
"Can not downgrade."

The system was running DSM 86009 Update 3, but the base .pat was just 86009. From synoupgrade’s perspective, this was a downgrade.

We modified both /etc/VERSION and /etc.defaults/VERSION, setting smallfixnumber from 3 to 0 — making the system believe it was running the base release. synoupgrade accepted the version change… and then returned a new error:

1
error_verify_patch (5222)

The firmware’s cryptographic signature check was failing. The full firmware .pat uses Synology’s proprietary encrypted format — not a tar, not a 7z, nothing standard. We couldn’t extract it manually, and we couldn’t make synoupgrade trust it.

We were stuck. Until we checked the Synology archive and found something we’d overlooked:

1
https://global.synologydownload.com/download/DSM/criticalupdate/
2
  update_pack/86009-3/synology_armada38x_ds218j.pat

3.15 megabytes. The Update 3 incremental patch — not the full firmware, just the delta from base 86009 to Update 3. And because our spoofed version was now base 86009, this was a legitimate upgrade, not a downgrade. No version games. No signature fights.

1
synoupgrade --patch /tmp/sm_update.pat
2
→ check_environment: success
3
→ unpack: success
4
→ update_files: success
5
→ version: success

282 out of 289 missing binaries: restored. The remaining 7 were directories, not files — the check had been using -f instead of -e. Everything was back.

The Final Miles

18:26–18:33

With the binaries restored, we reset the admin password (the original hash was unrecoverable), disabled the boot workaround service — the proper systemd units could now handle everything themselves — and rebooted.

The NAS didn’t come back immediately, and for a tense few minutes it seemed like it might not. But it did. STEP=4. 15 synocgid sockets. synoscgi listening. System info: DS218j, DSM 7.3.2-86009 Update 3, 40°C, uptime 2 minutes.

The login worked.

The Last Ghost: Missing CA Certificates

~20:00

After the reboot, almost everything worked — except the internet. wget https://www.google.com connected fine but threw an SSL certificate verification error. DNS resolved, TCP connected, but every HTTPS request failed. DSM couldn’t check for updates.

The firmware update had restored 282 system binaries, but it doesn’t touch the CA certificate store — that’s managed separately. A check revealed the damage: /etc/ssl/certs/ had been gutted from a full store of ~299 certificates down to just 13. The ca-certificates.crt bundle was gone entirely.

The fix was a two-step copy from the second NAS (both running the same DSM version). CA certificates are plain text PEM files — architecture-independent — so they could just be copied.

A final audit of the root filesystem — comparing modification timestamps between the incident window and the firmware update — found no other missing config. The only other traces of the incident were a leftover webui.bak file (DSM had auto-backed up its PAM config during recovery) and a package manager status record showing non-zero crash counts from when we’d been killing daemons. Both cleaned up in seconds.

What We Learned

A Synology NAS, even with most of its system binaries deleted, can be saved. The data volume is separate from the system. The boot sequence is just a file. The authentication layer is just a daemon with some sockets. The firmware update system — if you know how to talk to it — can put everything back, one layer at a time. And the CA certificate store, the one piece the firmware doesn’t restore, can be borrowed from a sibling NAS in a single pipe.

The NAS lived.
